Construction
1 piece construction
Constructions
Barrel and disc constructed as a unit. Usually referred to as European monoblock construction.
Advantages
The disc and barrel is molded together creating a 1-piece wheel unit. Thus, it is able to keep long-lasting rigidity. The 1-piece wheel is also simple and easy to manufacture, making it a cost efficient product for both manufacturers and consumers.
Specification
Catalogue
  Download pdf
Sizing
15", 16", 17", 18", 19"
PCD, Width & Offset
15 X 5.0 - [4-100 / +45] - Flat concave
15 X 6.5 - [4-100 / +42, +52] - Flat concave
15 X 8.0 - [4-100 / +5, +20] - Deep concave
[No custom PCD available]

16 X 5.5 - [4-100 / +45] - Flat concave
16 X 6.5 - [4-100 / +42, +52] - Flat concave
[No custom PCD available]

17 X 7.0 - [4-100, 4-114.3, 5-100, 5-114.3 / +38, +47, +53] - Flat concave
17 X 8.0 - [4-100, 4-114.3, 5-100, 5-114.3 / +35, +47] - Flat concave
17 X 9.0 - [5-100, 5-114.3 / +17, +28, +38] - Deep concave
[Custom PCD range: 4H-98 to 114.3 / 5H-100 to 120]

18 X 7.5 - [4-100, 4-114.3, 5-100, 5-114.3 / +38, +47, +53] - Flat concave
[Custom PCD range: 4H-98 to 114.3 / 5H-100 to 120]

18 X 8.5 - [5-100, 5-114.3 / +30, +38, +47] - Semi concave
18 X 9.5 - [5-100, 5-114.3 / +12, +20, +30, +38] - Deep concave
18 X 9.5 - [5-100, 5-114.3 / -15, +0] - Ultra deep concave
18 X 10.5 - [5-100, 5-114.3 / +15, +22] - Ultra deep concave
[Custom PCD range: 5H-100 to 120]

19 X 8.5 - [5-100, 5-114.3 / +25, +35, +42] - Semi concave
19 X 9.5 - [5-100, 5-114.3 / +15, +25, +38] - Deep concave
19 X 10.5 - [5-100, 5-114.3 / +12, +22, +32] - Ultra deep concave
19 X 11.0 - [5-100, 5-114.3 / +18] - Ultra deep concave *Discontinued*
[Custom PCD range: 5H-100 to 120]
Wheel colour options
AHG Bronze [AHG] - Standard
Matt Black [MBL] - Standard
White [WHT] - Standard
Glim Silver [GTS] - Additional cost
Work Metal Bright [WMB] -  Discontinued

COLORISM
Cassis Haze [CHP] - Additional cost
Energy Mint [EMP] - Additional cost
Kiwi Power [KWP] - Additional cost
Mandarin Alert [MAO] - Additional cost

CANDY COLOR
Candy Blue [CAB] - Additional cost
Candy Red [CAR] - Additional cost
Included with each wheel
1 X Black V29K2 valve
1 X Decal
IMPORTANT NOTICE
It is the buyer's responsibility to ensure that the wheels fit the car and thorough research is strongly recommended. Brake clearance varies with each spec, pleace contact us if in doubt.
Optional items
Center caps options
WORK X JDM CONCEPT CAP
EMOTION BLACK LOW CAP
EMOTION BLACK HIGH CAP
EMOTION SILVER LOW CAP
EMOTION SILVER HIGH CAP
EMOTION RED LOW CAP
EMOTION RED HIGH CAP
EMOTION BLUE LOW CAP
EMOTION BLUE HIGH CAP
EMOTION CAP COMPARISON
MCO BLACK LOW CAP
Wheels valves options
BLACK [V29K2]
BLUE [V29B2]
RED [V29R2]
